Product Description
-
Key Features
-
Ultra HD display with up to 3840 × 2160 resolution of input signal available
-
20px ultra fine writing, and 2 mm diameter recognizable with the precision of 1 mm
-
Built-in Wi-Fi projection without any cable connection
-
Built-in interactive whiteboard system allows annotating and sharing by QR code
-
Looping-out display available
-
Various audio and video interfaces for device access
-
Built-in network switch chip saves a network switch
-
Built-in Android system provides kinds of applications
-
Compatible with OPS/OPS-C devices, realizing smooth switch between built-in systems
-
Ultra-thin design with aluminum profile frame
Product Specification
| Brand | Hikvision |
| Product Type | Flat Panel Display |
| Product Model | DS-D5B86RB/C |
| Display | |
| Screen Size | 86 inch LED Backlight |
| Backlight | DLED |
| Pixel Pitch | 0.164 (H) × 0.493 (V) mm |
| Resolution | 3840 × 2160@60 Hz |
| Brightness | 350 cd/m² |
| Color Depth | 10 bit |
| Contrast Ratio | 4000 : 1 (Typ.) |
| Response Time | 6 ms |
| Color Gamut | 90% NTSC (CIE1931) (Typ.) |
| Refresh Rate | 60 Hz |
| Viewing Angle | 178° (H) / 178° (V) |
| Touch | |
| Type | Infrared touch screen |
| Glass | AG smooth glass |
| Touch Point | Max 45 point multi-touch |
| Touch Response Time | ＜ 10 ms |
| Touch Precision | ± 1 mm (≥ 90% touching area) |
| Built-in System | |
| Operation System | Android 11 |
| Processor | A72*2 A53*4,1.8 GHz |
| Memory | 4 GB |
| Built-In Storage | 64 GB |
| NIC | Built-in 1000 Mbps NIC, supporting routing; IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO, supporting both 2.4 GHz and 5GHz bands |
| Internal Function | |
| Loudspeaker | Built-in 2 × 16 W loudspeaker |
| Bluetooth | Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.0 and previous version |
| Interface | |
| Video & Audio Input | HDMI IN × 2,MAX 4K @30 Hz,LINE IN × 1 |
| Video & Audio Output | HDMI OUT(HDMI 2.0)×1,MAX 4K @60 Hz,LINE OUT × 1 |
| Control Interface | RS-232 × 1,Touch-USB × 1 |
| Network Interface | RJ45 (1000 Mbps port) × 2 |
| Data Transmission Interface | USB-C × 1, USB-A × 2 on front panel, USB-A × 2 on rear panel |
| Power | |
| Power Consumption | ≤ 490 W (full load) |
| Standby Consumption | 0.5 W |
| Working Environment | |
| Working Temperature | 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 10% to 90% RH |
| General | |
| Power | 100 to 240 V, AC, 50/60 Hz |
| Lifespan | 50000 hours |
| Product Dimensions(WxHxD) | 1963 × 1159 × 87.5 mm |
Hikvision 4K Smart Interactive Flat Panel Display 86 Inch DS-D5B86RB/C$ 52.77 $ 68.60 Please select combo product attributes
